Forged Steel Globe Valve, API 602, 1/2 IN, CL 800 LB, A105N

Name: Forged Steel Globe Valve, API 602, 1/2 IN, CL 800 LB, A105N
SKU: Kelly-GLV-20240823-02
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Our 1/2-inch, Class 800 LB forged steel globe valve is manufactured to API 602 standards. Constructed with a valve body of ASTM A105N+STL, it features a pass-through type design for efficient flow. The valve connects via threaded (THD) connections and is operated with a handwheel for precise control. Engineered for high-pressure applications, this globe valve combines robust construction with user-friendly operation, ensuring reliable performance and durability in demanding environments.

Request a quote

Quick Detail

Type	Forged Steel Globe Valve
Size	1/2 Inch, DN15
Pressure	800 LB, PN130
Connection	THD
Operation	Hand Wheel
Body Material	ASTM A105N+STL
Design Norm	API 602
Face to Face Dimensions	Manufacturer's Std.
NPT Ends Dimensions	ANSI B1.20.1
Test & Inspection Code	API 598
Applicable Medium	Water, Oil and Gas

Detail Information

On this page

Features

1. Durable Construction: Forged steel globe valves offer extended service life thanks to their high strength and wear resistance, which minimizes maintenance and replacement costs.

2. Efficient Operation: Designed for ease of use, these valves feature low operating torque, making them ideal for applications requiring frequent opening and closing.
