Dual Plate Wafer Check Valve, A352 LCC, API 594, 12 IN, 300 LB

Name: Dual Plate Wafer Check Valve, A352 LCC, API 594, 12 IN, 300 LB
SKU: Kelly-CV-20240731-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Our 12 Inch 300 LB wafer check valve is engineered to meet API 594 standards, featuring a robust body crafted from ASTM A352 LCC material. This valve boasts a double disc, built-in design, which enhances its structural integrity and operational reliability. It utilizes a wafer-style connection, ensuring a streamlined and efficient integration into various pipeline systems.

Request a quote

Quick Detail

Product Description

Type:	Wafer Check Valve
Size:	12 Inch
Pressure:	Class 300 LB
Connection:	Wafer
Body Material:	ASTM A352 LCC
Design Norm:	API 594
Pressure-temperature:	ANSl B16.34
Flange Ends:	ANSI B16.5
Face to Face Dimension:	APl 594
Test & Inspection Code:	API 598
Temperature:	-20 to 200°C
Applicable Medium:	Water, Oil and Gas

Detail Information

On this page

ASTM A352 LCC Check Valve, Carbon Steel, API 594, 12 IN, 300 LB

Features

1. Cost-Effective Manufacturing: Offers moderate production costs and high overall cost-effectiveness, making it ideal for large-scale applications and widespread use.

2. Compact Design: Lightweight and space-efficient, this valve is perfect for pipeline systems with limited space, particularly those with narrow gaps between pipelines.
