API 6D Trunnion Mounted Ball Valves, A351 CF8M, 2 IN, 300 LB

Name: API 6D Trunnion Mounted Ball Valves, A351 CF8M, 2 IN, 300 LB
SKU: Kelly-BV-20240802-03
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The 2 Inch Class 300 LB trunnion mounted ball valve is manufactured in compliance with the API 6D standard. Constructed from ASTM A351 CF8M, this valve features a full bore design with a fixed ball for optimal performance. It includes safety enhancements such as anti-fire, anti-static, and anti-blowout valve stem features. The connection type is raised face (RF), and it is operated via a lever mechanism, ensuring reliable and easy handling.

Request a quote

Quick Detail

Type:	Trunnion Mounted Ball Valve
Design Standard:	API 6D
Size:	2 Inch, DN50
Pressure:	CL 300 LB
Connection:	RF
Operation:	Lever
Body Material:	ASTM A351 CF8M, Stainless Steel
Face to Face Dimensions:	ASME B16.10
Flange Ends Dimensions:	ASME B16.5
Fire Safe:	API 607
Test & Inspection Code:	API 598
Temperature:	-29 to 120°C
Applicable Medium:	Water, Oil and Gas

Detail Information

On this page

Trunnion Mounted Ball Valve, API 6D, ASTM A351 CF8M Body, 2 Inch, 300 LB, RF Connection, Lever.

Features

1. Bidirectional Sealing: The fixed ball valve design allows medium flow in both directions, ensuring reliable bidirectional sealing and preventing reverse flow.
2. Low Operating Torque: The stationary ball design results in relatively low operating torque, making it particularly suitable for large-diameter and high-pressure applications, and facilitating easier manual or automated operation.
