10-inch Dual Plate Wafer Check Valve, API 594, LCC, 150 LB

Name: 10-inch Dual Plate Wafer Check Valve, API 594, LCC, 150 LB
SKU: Kelly-CV-20240921-02
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The 10-inch Class 150 LB dual plate wafer check valve is engineered to meet the API 594 standard, ensuring high performance and reliability. Constructed from ASTM A352 LCC combined with 316 stainless steel, the valve body provides exceptional strength and corrosion resistance. Featuring a double disc design, this check valve allows for efficient fluid flow while minimizing pressure drop. It is equipped with an RF (raised face) connection for secure integration into various pipeline systems, making it an ideal choice for a wide range of industrial applications.

Request a quote

Quick Detail

Type	Wafer Check Valve
Size	10 Inch, DN250
Pressure	Class 150 LB, PN16
Connection	RF
Body Material	ASTM A352 LCC+316
Design Norm	API 594
Pressure-Temperature	ANSI B16.34
Flange Ends	ANSI B16.5
Face to Face Dimension	API 594
Test & Inspection Code	API 598
Temperature	≤ 300°C
Applicable Medium	Water, Oil and Gas

Detail Information

On this page

Features

1. Simple design with a low failure rate, making maintenance easy and reducing both operational and maintenance costs.

2. Minimal resistance when fluid flows through, helping to maintain system flow and pressure balance efficiently.
