API 602 Lift Check Valve, ASTM A182 F316L, 1 Inch, 800 LB

Name: API 602 Lift Check Valve, ASTM A182 F316L, 1 Inch, 800 LB
SKU: Kelly-CV-20240816-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The 1-inch 800 LB lift check valve, crafted to API 602 standards, features a robust design with a body made from ASTM A182 F316L stainless steel combined with STL. This valve utilizes a lift-type structure for reliable performance and is connected via a socket weld (SW) method. Its high-grade materials and precise construction ensure durability and optimal functionality in demanding applications.

Request a quote

Quick Detail

Type	Lift Check Valve
Size	1 Inch
Pressure	CL 800 LB
Connection	SW
Body Material	ASTM A182 F316L+STL
Design Norm	API 602
Face to Face Dimensions	Manufacturer's Std.
Flange Ends Dimensions	ANSI B16.11
Test & Inspection Code	API 598
Temperature	-29°C - 425°C
Applicable Medium	Water, Oil and Gas

Detail Information

On this page

Features

1. The valve boasts a straightforward structural design, making it easy to maintain and inspect. The valve disc and seat ring are simple to replace or repair, enhancing convenience.

2. It offers excellent sealing performance, effectively preventing medium leakage and ensuring the safety of the system.
