2 Piece Floating Ball Valve, API 6D, CF8M, 1-1/2 Inch, CL150

Name: 2 Piece Floating Ball Valve, API 6D, CF8M, 1-1/2 Inch, CL150
SKU: VPSK-20250424-BAV-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The 2-Piece Floating Ball Valve Plant is designed for reliable flow control in various industrial applications. Made from cast stainless steel (ASTM A351 CF8M), this valve features a 1-1/2 inch (DN40) size and is rated for Class 150 LB and PN20 pressure. It complies with API 6D standards, ensuring durability and performance. The lever-operated valve has RF flanged ends for secure connections, providing efficient and dependable shut-off in fluid systems.

Request a quote

Detail Information

Product Name: 2 Piece Floating Ball Valve
Design Standard: API 6D
Body Material: ASTM A351 CF8M
Size: 1-1/2 Inch, DN40
Pressure Rating: Class 150 LB, PN20
Face to Face: ANSI B16.10
Test & Inspection: API 598
Flange End: ANSI B16.5
End Connection: RF Flanged Ends
Operation: Lever
Applicable Media: Water, Oil, Gas, etc

Send your message to this supplier

Name *

Company

Email *

Phone

Message *

FAQs

Can you supply valves with 3.2 certification?

Yes, 3.2 certificates are available at an additional cost. We work with reputable third-party inspection agencies (TPI) such as BV, TUV, SGS, or LR, who will inspect the valves and issue signed certificates provided with the shipment.

¿Pueden suministrar válvulas con certificación 3.2?

Sí, el certificado 3.2 está disponible con coste adicional. Contamos con organismos de inspección reconocidos como BV/TUV/SGS/LR para inspeccionar las válvulas. Los certificados serán firmados y emitidos por estos TPI y se entregarán junto con las válvulas.

Можете ли вы поставить клапаны с сертификатом 3.2?

Да, сертификат 3.2 доступен за дополнительную плату. Мы привлекаем авторитетные третьи инспекционные организации (TPI), такие как BV, TUV, SGS, LR, для инспекции клапанов. Сертификаты подписываются и выдаются этими организациями и предоставляются вместе с клапанами.
