BS EN 13709 Y Type Strainer, DN80, PN40, EN 10213 1.0619

Name: BS EN 13709 Y Type Strainer, DN80, PN40, EN 10213 1.0619
SKU: Kelly-ST-20240921-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The DN80 PN40 Y-type strainer is designed in compliance with the BS EN 13709 standard, ensuring reliable performance in demanding applications. Crafted from high-quality EN 10213 1.0619 material, the valve body offers durability and strength. Featuring a Y-shaped structure with a mesh size of 0.25 mm, the strainer effectively filters out debris without a drain plug. It is equipped with an RF (raised face) connection, providing a secure and efficient seal for various pipeline systems, making it ideal for use in high-pressure environments.

Request a quote

Quick Detail

Type	Y Type Strainer
Size	DN80
Pressure	PN40
Connection	RF
Body Material	EN 10213 1.0619
Design Norm	BS EN 13709
Face to Face Dimensions	BS EN 558-1 S.1
Flange Ends Dimensions	BS EN 1092-B1
Test & Inspection Code	BS EN 12266
Applicable Medium	Water, Oil and Gas

Detail Information

On this page

Features

1. Offers excellent pressure and temperature resistance, making it suitable for various operating conditions.

2. Y-shaped filters are typically installed at the inlet of pipeline systems or ahead of key equipment. They can be mounted either horizontally or vertically, providing versatile installation options.
