ASTM A105N Bellow Seal Gate Valve, 1 Inch, 800 LB

Name: ASTM A105N Bellow Seal Gate Valve, 1 Inch, 800 LB
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

ASTM A105N Bellow Seal Gate Valve Supplier: Bellow Seal Gate Valves, 1 Inch, Class 800 LB, ASTM A105N, API 602, ASME B16.34, BB, OS & Y, SW Ends.

Request a quote

Quick Detail

Type	Gate Valve
Size	1 Inch
Pressure	Class 800
Construction	BB, OS&Y, Bellow Seal
Connection	Socket Weld
Operation	Handwheel
Body Material	Forged Steel A105
Design Code	API 602, ASME B16.34
Face to Face Code	ANSI B16.10
Pressure & Temp Code	ANSI B16.34
Test & Inspection Code	API 598
Temperature Range	-29℃~+425℃
Medium	Water, Oil and Gas
Origin	China

Detail Information

Bellow Seal Gate Valve 1 Inch 800 LB ASTM A105N SW

The 1-inch bellow sealed gate valve comprises bolted bonnet, outside screw, yoke and 800 LB socket weld end. The design standard is API 602 and the inspection standard is API 598.

Features

1. Simple structure, Convenient for manufacturing and maintenance;
2. Short opening and closing time;
3. Good sealing performance, small friction between sealing surfaces, and long service life.
