API 6D Two-piece Floating Ball Valve, ASTM A182 F51, 150 LB

Name: API 6D Two-piece Floating Ball Valve, ASTM A182 F51, 150 LB
SKU: Kelly-BV-20240906-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The 2 x 1-1/2 Inch, 150 LB floating ball valve is designed to API 6D standards and features a body made from ASTM A182 F51. This valve has a two-piece construction with a floating ball and reduced diameter, incorporating anti-fire, anti-static, and anti-flying valve stem properties. It supports bidirectional flow and includes a locking device for enhanced safety. With RF connections and lever operation, this valve ensures reliable performance and ease of control across various industrial applications. As a leading ball valve manufacturer from China, we are committed to delivering superior quality and performance.

Request a quote

Quick Detail

Type	Floating Ball Valve
Size	2x1.5 Inch
Pressure	Class 150 LB
Connection	RF
Operation	Lever
Body Material	ASTM A182 F51
Design Norm	API 6D
Pressure / Temperature	ASME B16.34
Face to Face	API 6D
Flange	ASME B16.5
Test & Inspection Code	API 598
Temperature	0 - 100°C
Applicable Medium	Water, Oil and Gas

Detail Information

On this page

RF Flanged Floating Ball Valve, ASTM A182 F51 Body, Anti-fire Design.

Features

1. Two-piece floating ball valves are typically operated with a handle or actuator, allowing for easy 90-degree rotation to open or close the valve. They require minimal operating torque and provide quick, efficient operation.

2. The ball in a floating ball valve creates a secure seal by tightly pressing against the downstream seat under fluid pressure, ensuring reliable and effective sealing.
