API 6D Trunnion Mounted Ball Valve, DN100, PN16, ASTM A105

Name: API 6D Trunnion Mounted Ball Valve, DN100, PN16, ASTM A105
SKU: Kelly-BV-20240731-03
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Our DN100 PN16 trunnion-mounted ball valve, crafted to API 6D standards, features a robust ASTM A105 body. Designed with a fixed ball and a full-bore structure, this valve offers enhanced flow capacity and operational reliability. It includes key safety features such as fire resistance, anti-static properties, and a secure anti-flying valve stem. The valve connects via EN 1092-1 B flanges and is operated by a lever, ensuring straightforward and efficient control.

Request a quote

Quick Detail

Product Description

Type:	Trunnion Mounted Ball Valve
Size:	DN100, 4 Inch
Pressure:	PN16, CL 150 LB
Connection:	EN 1092-1 B
Operation:	Lever
Body Material:	ASTM A105, Carbon Steel
Design Norm:	API 6D
Pressure/Temperature:	EN 1092
Face to Face:	EN 558-1
Flange:	EN 1092-1 (B1)
Test & Inspection Code:	API 6D
Applicable Medium:	Water, Oil and Gas
Temperature:	-29 to 121°C

Detail Information

On this page

Carbon Steel Trunnion Mounted Ball Valve, API 6D, DN100, PN16, ASTM A105

Features

1. Cost-Effective Manufacturing: Offers moderate production costs and high overall cost-effectiveness, making it suitable for large-scale applications and widespread use.

2. Excellent Sealing Performance: Ensures effective prevention of medium leakage, reducing environmental pollution and meeting stringent environmental protection standards.
