API 594 Dual Plate Wafer Check Valve, A351 CF8, 2 IN, CL150

Name: API 594 Dual Plate Wafer Check Valve, A351 CF8, 2 IN, CL150
SKU: Kelly-CV-20240927-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The 2-inch 150 LB dual plate wafer check valve is manufactured in compliance with API 594 standards. The valve body is constructed from ASTM A351 CF8 stainless steel, offering durability and corrosion resistance. Featuring a double disc design and wafer-type structure, this valve ensures efficient flow control. Its connection method is wafer-style, making it a reliable solution for various pipeline applications.

Request a quote

Quick Detail

Type	Wafer Check Valve
Size	2 Inch, DN50
Pressure	Class 150 LB, PN16
Connection	Wafer
Body Material	ASTM A351 CF8
Design Norm	API 594
Pressure-Temperature	DIN 2401
Flange Ends	EN 1092-1
Face to Face Dimension	APl 594
Test & Inspection Code	API 598
Applicable Medium	Water, Oil and Gas

Detail Information

On this page

Dual Plate Wafer Type Check Valve, CF8 Body, API 594 Design.

Features

1. The double disc wafer check valve features a compact clamp design with a short body, making it ideal for pipeline systems where installation space is limited.

2. Lightweight and easy to transport, install, and maintain, ensuring efficient operation and minimal upkeep.
