875kW Natural Gas Generator Set, Perkins 4016-61TRS1, 50 Hz

Name: 875kW Natural Gas Generator Set, Perkins 4016-61TRS1, 50 Hz
SKU: CGS-20250313-GGS-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The 875kW 1094kVA Natural Gas Generator Set from the factory features a Perkins 4016-61TRS1, 12-cylinder engine paired with a Stamford alternator. Operating at 50 Hz and delivering 400/230 V, this high-efficiency generator set provides a rated current of 1579 A, making it an ideal choice for reliable power supply in various industrial and commercial settings.

Request a quote

Detail Information

Product Name: Perkins 875kW Natural Gas Generator Set, High Efficiency
Fuel: Natural Gas
Engine: Perkins 4016-61TRS1
Alternator: Stamford S6L1D-F4
Cylinder Number: 12 Cylinders V Type
Power Factor: 0.8
Rated Power: 875kW, 1094kVA
Speed/Frequency: 1500 rpm/50 Hz
Voltage: 400/230 V
Rated Current: 1579 A
Starting Mode: 24 V/DC Electrical Starting
Dimensions: 5560 * 2600 * 2960 mm
Weight: 11,536 kg

Genset Voltage & Frequency Regulation

Steady Voltage Regulation	≤ ±1%
Transient Voltage Regulation	−15% ≤ δu ≤ +20%
Voltage Regulation Range	±5%
Voltage Wave Motion Rate	≤ ±1%
Voltage Recovery Time	≤ 4 s
Steady Frequency Regulation	≤ ±0.5%
Transient Frequency Regulation	−15% ≤ δf ≤ +10%
Frequency Fluctuation Rate	≤ ±0.5%
Frequency Steady Time	≤ 3 s

Engine Specifications

Brand	Perkins
Model	4016-61TRS1
Air Intake Way	Turbocharged, Air Cooled
Cooling Way	Closed Cooling Cycle
Cylinder / Arrangement	16 / V Type
Displacement	61 L
Bore	160 mm
Stroke	190 mm
Compression Ratio	12.0 : 1
Rated RPM @ 50 Hz	1500 rpm
Max. Standby Power @ 50 Hz	912 kW
Governor	Electronic
Dimensions (L × W × H)	2949 × 1737 × 1969 mm
Weight	6158 kg

Engine System Specifications

Air Intake System	Engine Air Flow	54 m³/min
Exhaust System	Exhaust Gas Flow	180 m³/min
	Exhaust Temperature	468 ± 25°C
	Max. Back Pressure	10 kPa
Fuel System	Fuel Type	Natural Gas
	Fuel Supply Pressure	20 - 50 kPa
	Main Composition	≥ 55%
	Fuel Consumption	136.3 m³/hr
Lubrication System	Oil Consumption @ 100% Load	≤ 0.25 g/kW·hr
	Total Oil Capacity	286 L
	Oil Pressure	470 kPa
Cooling System	Coolant Capacity	95 L
	Thermostat Range	83 – 95°C
	Max. Water Temperature	100°C

Alternator Specification

Brand	Stamford
Model	S6L1D-F4
Rated Power	920kW, 1150kVA
Voltage Classes	400 / 230 V
Phase	3 Phase
Power Factor	0.8
Excitation Way	Self-Excited
AVR Type	MX341
Rated Ambient Temperature	40°C
Bearing Number	1
Poles	4
Insulation Class	H
Temperature Rise	H
Protection Grade	IP23
Altitude	≤ 1000 m
Overspeed	2250 rpm
Total Harmonic Distortion (THD)	< 5%
Telephone Harmonic Factor (THF)	< 2%
Telephone Influence Factor (TIF)	< 50

Controller Specification

Operating Voltage	12V / 24V
Operating Current	12V: 380 mA
Operating Current	24V: 188 mA
Operating Temperature	−25°C to 70°C
Relative Humidity	20% – 93% RH
IP Rating (Front)	IP65
IP Rating (Back)	IP20
Mounting Hole Size	214 × 160 mm
Net Weight	0.85 kg
