4 Wheels Hydraulic Excavators with 0.35 m³ Bucket, 9 Tons
Key Specifications / Features
Meet the AB100S Wheeled Hydraulic Excavators-where performance and versatility unite. Model No.: AB100S, boasting an operating weight of 9000 kg and driven by a 62.5 kW engine, it outshines in a wide array of applications.Benefit from its 2000 mm tail swing radius, ensuring excellent maneuverability. The 0.35 m³ bucket capacity enhances efficiency during material handling.Travel at a maximum speed of 23 km/h, swiftly navigating between work areas. Enjoy a generous digging reach of 7000 mm and a digging depth of 3900 mm, perfect for deep excavation projects.Conquer challenging terrains effortlessly, thanks to the impressive 50 KN traction force and 30°/58% gradeability. The AB100S is your reliable companion for superior performance in any construction endeavor.
Request a quote
Detail Information
Model No.: AB100S
Products: 4 Wheels Hydraulic Excavators
Operating Weight: 9000 kg, 9 Ton
Engine Power: 62.5 kw
Tail Swing Radius: 2000 mm
Bucket Capacity: 0.35 m³
Max Travel Speed: 23 km/h
Max Digging Reach: 7000 mm
Max Digging Depth: 3900 mm
Max Traction Force: 50 KN
Gradeability: 30 °/58%
| Range of operation | |
| Boom length | 3830mm |
| Arm length | 1900mm |
| Maximum Digging Reach | 7000mm |
| Maximum Digging Depth | 3900mm |
| Maximum Digging Force | 60KN |
| Maximum Digging Height | 6800mm |
| Maximum Dumping Height | 4700mm |
| Back-end radius of gyration | 2000mm |
| Dimensions | |
| (Length*width*height) Transport Dimensions | 6500*2380*3050mm |
| Wheel base | 2600mm |
| Track(Front/rear) | 1930/1830mm |
| Ground clearance of counterweight | 1250mm |
| Min ground clearance | 250mm |
| Tech performance and specification | |
| Angle of rotation | 360° |
| Machine weight | 9000kg |
| Engine model | YUCHAI 4FA85 |
| Rated Power | 62.5KW |
| Rated Speed | 2200r/min |
| Hydraulic system working pressure | 24Mpa |
| Hydraulic system flow | 158L/min |
| Variable piston pump | 2*36ml/r |
| Max Traction Force | 50KN |
| Walking speed | 23km/h |
| Grade Climbing ability | 58%/30° |
| Tyre model | 8.25-20 |
| Full circle swinging time | 5.5s |
| Swing Overload Pressure | 20mpa |
| Volume Of Bucket | 0.35m³ |
| Fuel Quantity | ≥6L/h |
| Capacity Of The Fuel Tank | 130L |
| Hydraulic Tank Capacity | 120L |
