ASTM A351 CF8M Butterfly Valve, 12 IN, 300 LB, API 609, Lug

Name: ASTM A351 CF8M Butterfly Valve, 12 IN, 300 LB, API 609, Lug
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Discover a premium ASTM A351 CF8M butterfly valve crafted by a leading manufacturer. This valve boasts a size of 12 inches (DN300), with a pressure rating of 300 LB (PN50). Engineered to API 609 standards, it features a triple eccentric design and is constructed from high-quality stainless steel. Designed as a lug type valve, it offers both flanged and wafer configurations for versatile installation options.

Request a quote

Detail Information

Triple Eccentric Butterfly Valve, Stainless steel, NPS 12, 300 LB, LUG.

Descripción de la válvula:
Triple Eccentric Butterfly Valve, LUG.
Design: API 609.
Cuerpo: ASTM A351 CF8M
Tamaño nominal: 12 pulgadas.
Nivel nominal: 300 libras.
Conexión final: orejetas.
Face to face: APPI 609.
Prueba e inspección: API 598.

Alcance del producto:
Material corporal: acero inoxidable.
Diámetro normal: 2-32 pulgadas (DN50-DN800).
End connection: Flanged, WAFER, LUG.
Rango de presión: 150-600 libras (PN16-PN100).
Temperatura de funcionamiento: -29 ℃-+ 300 ℃.

Parámetros técnicos y características

Product	Triple Eccentric Butterfly Valve.
Nominal diameter	2 Inch - 32 Inch.
Design temp.	Down to -29℃.
Design pressure	Class 150 - 600 LB.
Material	Stainless steel.
Design standard	API 609.
Face to face	API 609.
Connection end	Flange, WAFER, LUG.
Test standard	API 598.
Package	Plywood
Application	water, oil and gas.
