Orbit Ball Valve Packing, ISO 15848, Graphite, 32 mm * 48 mm

The China Orbit Ball Valve Packing Factory specializes in producing low-emission packing sets for orbit ball valves. These packing sets are designed to meet the stringent requirements of TA-Luft and ISO 15848, ensuring minimal fugitive emissions and high performance. Each set features five rings made from high-quality graphite, reinforced with Inconel 600 for enhanced durability and corrosion resistance. The packing has an inner diameter of 32 mm and an outer diameter of 48 mm, making it suitable for a wide range of orbit ball valve applications.

Product Name: Low Emission Packing Set for Class 2500 LB Orbit Ball Valve
Inner Diameter (ID): 32 mm
Outer Diameter (OD): 48 mm
Number of Packing Rings: 5 Rings
Application: Class 2500 LB Orbit Ball Valve
Material Properties:
Graphite Purity: ≥99%
Metal Wire Content: 20% (Inconel 600)
Sulfur Content: ≤50 PPM
Chlorine Content: ≤20 PPM
Temperature Range: -50°C to +300°C
Speed: 2 m/s
pH Value: 0 to 14
Pressure: 25 MPa
Media: solvents, hydrocarbons, acids, alkalis, steam, alcohol, oil
Certifications: TA-Luft, ISO 15848, API 589 (Fire Safe)

Product Introduction

The Orbit Ball Valve Stem features a unique combination of rotational and lifting motions, ensuring smooth operation. When subjected to high pressures of up to Class 2500 LB, the valve generates significant torque. However, our customers demand low torque, exceptional high-pressure sealing, and reliable performance even under fluctuating high and low temperatures.
To address these requirements, we have designed the valve stem with an upper and lower V-shaped structure. This innovative design reduces friction while maintaining adequate sealing stress. Additionally, we have reinforced the graphite material to enhance its strength and buffering capabilities, ensuring consistent performance under demanding conditions.
