3PCS Body Forged Trunnion Mounted Ball Valve
Key Specifications / Features
China Forged Trunnion Mounted Ball Valve Manufacturer: 3PCS Body Forged Trunnion Mounted Ball Valve, ASTM A105N, ASME B16.34, 2 - 24 Inch, Class 150 - 2500 LB.
Request a quote
Detail Information
Body material: ASTM A105N, ASTM A182 F316, ASTM A350 LF2
Size: 2 Inch - 24 Inch
Class: 150 - 2500 LB
Three Pieces Forged Steel Body
Trunnion Mounted Ball, Full & Reduced Bore
Anti-static Device
Blow-out Proof Stem
Double Block and Bleed
Fire Safe Design
Emergency Sealant Injector (6 Inch & Larger)
Vent Valve and Safety Valve
Lifting Lugs & Supporting Feet (8 Inch & Larger)
Seat Pocket SS Overlay (Optional)
Seals Area ENP Coated
Design: ASME B16.34/API 6D
Face to Face: ASME B16.10/API 6D
End to End: ASME B16.10/API 6D
End Flange: ASME B16.5/B16.47A
BW End: ASME B16.25
Test: API 6D
Fire Safe Test: API 607/API 6FA
Special: NACE MR0175
Size: 2 Inch - 24 Inch
Class: 150 - 2500 LB
Three Pieces Forged Steel Body
Trunnion Mounted Ball, Full & Reduced Bore
Anti-static Device
Blow-out Proof Stem
Double Block and Bleed
Fire Safe Design
Emergency Sealant Injector (6 Inch & Larger)
Vent Valve and Safety Valve
Lifting Lugs & Supporting Feet (8 Inch & Larger)
Seat Pocket SS Overlay (Optional)
Seals Area ENP Coated
Design: ASME B16.34/API 6D
Face to Face: ASME B16.10/API 6D
End to End: ASME B16.10/API 6D
End Flange: ASME B16.5/B16.47A
BW End: ASME B16.25
Test: API 6D
Fire Safe Test: API 607/API 6FA
Special: NACE MR0175
| MATERIAL SPECIFICATIONS | |||||
| No. | Part | A105/ENP | A105/316 | F316/316 | LF2/316 NACE |
| 1 | Body | ASTM A105N | ASTM A105N | ASTM A182-F316 | ASTM A350-LF2 |
| 2 | Adapter | ASTM A105N | ASTM A105N | ASTM A182-F316 | ASTM A350-LF2 |
| 3 | Ball | ASTM A105N/ENP AISI 4140/ENP (2500LB) |
ASTM A182-F316 ASTM A182-F51 (900LB~2500LB) |
ASTM A182-F316 ASTM A182-F51 (900LB~2500LB) |
ASTM A182-F316 ASTM A182-F51 (900LB~2500LB) |
| 4 | Seat Insert | PTFE/Molon/PEEK | PTFE/Molon/PEEK | PTFE/Molon/PEEK | PTFE/Molon/PEEK |
| 5 | Seat Ring | ASTM A105N/ENP | ASTM A182-F316 | ASTM A182-F316 | ASTM A182-F316 |
| 6 | Stem | AISI 4140/ENP | ASTM A182-F51 | ASTM A182-F51 | ASTM A182-F51 |
| 7 | Trunnion Support | ASTM A105N/ENP | ASTM A105N/ENP | ASTM A182-F316 | ASTM A350-LF2/ENP |
| 8 | Gland Flange | ASTM A105N/ENP | ASTM A105N/ENP | ASTM A182-F316 | ASTM A350-LF2/ENP |
| 9 | Top Flange | ASTM A105N | ASTM A105N | ASTM A182-F316 | ASTM A350-LF2 |
| 10 | Body Stud | ASTM A193-B7 | ASTM A193-B7 | ASTM A193-B8 | ASTM A320-L7M |
| 11 | Body Nut | ASTM A194-2H | ASTM A194-2H | ASTM A194-8 | ASTM A194-7M |
| 12 | Screw | Carbon Steel | Carbon Steel | Stainless Steel | ASTM A320-L7M |
| 13 | Screw | Carbon Steel | Carbon Steel | Stainless Steel | ASTM A320-L7M |
| 14 | Body Gasket | Braided Graphite | Braided Graphite | Braided Graphite | Braided Graphite |
| 15 | Gland Gasket | Graphite | Graphite | Graphite | Graphite |
| 16 | Stem Firesafe Packing | Graphite | Graphite | Graphite | Graphite |
| 17 | Seat Firesafe Packing | Braided Graphite | Braided Graphite | Braided Graphite | Braided Graphite |
| 18 | Thrust Washer | PTFE/SS+Copper | PTFE/SS+Copper | PTFE/SS+Copper | PTFE/SS+Copper |
| 19 | Washer | PTFE/SS+Copper | PTFE/SS+Copper | PTFE/SS+Copper | PTFE/SS+Copper |
| 20 | Bearing | SS+Copper+PTFE | SS+Copper+PTFE | SS+Copper+PTFE | SS+Copper+PTFE |
| 21 | O-ring | Viton | Viton | Viton | Viton |
| 22 | O-ring | Viton | Viton | Viton | Viton |
| 23 | O-ring | Viton | Viton | Viton | Viton |
| 24 | O-ring | Viton | Viton | Viton | Viton |
| 25 | Vent Valve | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| 26 | Drain | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| 27 | Stem Injection | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| 28 | Seat Injection | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| 29 | Check Valve | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| 30 | Seat Spring | Inconel X-750 | Inconel X-750 | Inconel X-750 | Inconel X-750 |
| 31 | Antistatic Spring | Inconel X-750 | Inconel X-750 | Inconel X-750 | Inconel X-750 |
| 32 | Antistatic Spring | Inconel X-750 | Inconel X-750 | Inconel X-750 | Inconel X-750 |
| 33 | Grounding Plunger | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| 34 | ALignment Pin | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| 35 | Gland Pin | Carbon Steel | Carbon Steel | Stainless Steel | Carbon Steel |
| 36 | key | Carbon Stee | Carbon Steel | Stainless Steel | Carbon Steel |
