Circuit Analyzer MS5908

Name: Circuit Analyzer MS5908
SKU: MS5908
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

MS5908 Circuit Analyzer to identify wiring problems that can lead to personal shock hazards,electrical fires,or equipment performance issues.

Request a quote

Detail Information

♦Ture RMS
♦Measures voltage:line,ground-to-neutral,peak,frequency.
♦Measures voltage drop under 5,8 and 10-amp loads.
♦Measures hot,neutral and ground conductor impedances.
♦Identifies proper wiring in 3-wire receptacles.
♦Tests RCD for proper operation.
♦Tests GFCI for proper operation.

Specifications
Measurement	Ranges	Resolution	Accuracy
Line voltage	85.0~265.0V	0.1V	±(1.0%+0.2V)
Neutral-ground V	0.0~10.0V	0.1V	±(2.5%+0.2V)
Peak line voltage	121.0~374.0V	0.1V	±(1.0%+0.2V)
Frequency	45.0~65.0HZ	0.1HZ	±(1.0%+0.2HZ)
% voltage drop	0.1%~99.9%	0.10%	±(2.5%+0.2%)
Voltage loaded	10.0~265.0V	0.1V	±(2.5%+0.2V)
Impedance-hot	0.00~3.00Ω	0.01Ω	±(2.5%+0.02Ω)
Neutral,&ground	>3.00Ω		unspecified
RCD trip time	1ms~6.500s	1ms	±(1.0%+2ms)
RCD trip current	30mA	0.1mA	±(1.0%+0.2mA)
GFCI trip time	1ms~6.500s	1ms	±(1.0%+2ms)
GFCI trip current	60mA	0.1mA	±(1.0%+0.2mA)
