Stainless Steel Ball Valves, A182 F316, 1 Inch, CL1500, 3 PC

The China Stainless Steel Ball Valves Supplier offers high-quality ball valves designed to meet ASME B16.34 standards. These 3-piece ball valves are constructed from ASTM A182 F316 stainless steel, providing excellent corrosion resistance and durability. With a 1-inch (DN25) size and a pressure rating of 1500 LB (PN250), they are suitable for demanding applications. The valves feature female national pipe thread (FNPT) ends for secure connections and are lever operated for easy control.

Product Name: Forged Ball Valve, 3 Pieces
Design Standard: ASME B16.34
Body Material: ASTM A182 F316
Size: 1 Inch, DN25
Pressure: Class 1500 LB, PN250
End Connection: FNPT Threaded
Operation: Lever
Medium: Water, Oil, Gas, etc
Temperature Range: -29°C to 150°C

Forged Steel Ball Valves are available in two types: Two-Piece Split Body and Three-Piece Bolted Body. The forging material ensures sufficient rigidity and strength under the maximum rated operating pressure, eliminating the inherent flaws associated with cast materials. The valves feature adequate wall thickness and the use of high-strength tie bolts, which facilitate maintenance and provide the necessary strength to withstand pipeline stress. The internal components of the valve are meticulously designed and selected to ensure reliability under a variety of working conditions.

Technical Specification

» Type: Forged Steel Ball Valve
» Size Range: 1/2 inch to 2 inches for forged items
» Temperature Range: -29°C to 150°C
» Design Pressure: Class 150 to 1500 LB (PN10-PN250)
» Materials: Carbon Steel, Alloy Steel, Stainless Steel, Duplex Steel, and other materials
» Trim Materials: 13%Cr, SS 304, SS 304L, SS 316, SS 316L, and other special materials
» Seat Materials: PTFE, RPTFE, PEEK
» End Connections: SW, FNPT, BW
» Design and Manufacture: ASME B16.34, API 602
» Face to Face (End to End): ANSI B16.10
» Flanged Connection: ANSI B16.5
» Test and Inspection: API 598, API 6D
» Butt Welded End: ANSI B16.9
» Threaded Ends: ASME B1.20.1
» Socket-Weld Ends: ASME B16.11

Product Features

Forged Steel Floating Ball Valves are available in three types: One-Piece Uni-body, Two-Piece Split Body, and Three-Piece Bolted Body. These valves are designed and manufactured in accordance with the most up-to-date international standards, including API 6D, ASME B16.34, BS 5351, or equivalents. The standard features of these valves include Fire Safe, Anti-static, and Blow-out prevention.
