ASTM A351 CF8M Floating Ball Valve, 4 Inch, 150 LB, API 6D, RF

Name: ASTM A351 CF8M Floating Ball Valve, 4 Inch, 150 LB, API 6D, RF
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

4 Inch 150 LB floating ball valve is made according to API 6D standard. The valve body is made of A351-CF8M. It has the structural characteristics of split type, side-mounted, floating ball, and full bore. Its connection mode is RF. It has a lever operation mode.

Request a quote

Quick Detail

Product Description

Type	Floating Ball Valve
Size	4 Inch
Pressure	150 LB
Connection	RF
Operation	Lever
Body Material	ASTM A351-CF8M
Design Norm	API 6D
Face to Face Dimensions	ASME B16.10
Flange ends Dimensions	ASME B16.5
Fire Safe Design	API 607
Test & Inspection Code	API 598
Temperature	-29 - 120°C
Applicable Medium	Water, Oil and Gas

Detail Information

4 Inch 150 LB Floating Ball Valve RF CF8M API 6D Lever

Features

1. Due to the floating design of the sphere, floating ball valves are usually able to provide more precise flow control;

2. The most significant feature of a floating ball valve is that the ball inside the valve body can float. This sphere can float up and down as the fluid changes, adjusting the opening and closing degrees of the valve.

Technical Drawing
