ASTM A105 Tilting Disc Check Valve, API 6D, 10 IN, 1500 LB

Name: ASTM A105 Tilting Disc Check Valve, API 6D, 10 IN, 1500 LB
SKU: Kelly-CV-20240816-02
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The 10-inch 1500 LB tilting disc check valve, manufactured to API 6D standards, features a robust construction with a valve body crafted from ASTM A105 steel combined with STL. Designed with a swash plate type structure, this valve ensures efficient flow control and reliable operation. The connection is achieved through a raised face (RTJ) joint, which provides a secure and leak-proof seal. This valve is ideal for high-pressure applications where durability and performance are critical. As a leading check valve manufacturer in China, we ensure top-quality products that meet stringent industry standards.

Request a quote

Quick Detail

Type	Tilting Disc Check Valve
Size	10 Inch
Pressure	Class 1500 LB
Connection	RTJ
Body Material	ASTM A105+STL
Design Norm	API 6D
Face to Face Dimensions	API 6D
End Flange Dimensions	ANSl B16.5
Test & Inspection Code	API 6D
Temperature	-29 ~ 300°C
Applicable Medium	Water, Oil and Gas

Detail Information

On this page

Features

1. Cost-effective with moderate manufacturing and maintenance expenses, this valve is ideal for large-scale applications and widespread use.

2. Excellent sealing performance effectively prevents medium leakage, minimizes environmental pollution, and adheres to environmental protection standards.
