ASME B16.34 Y Strainer, 3 Inch, 150 LB, ASTM A352 LCB, RF

Name: ASME B16.34 Y Strainer, 3 Inch, 150 LB, ASTM A352 LCB, RF
SKU: Kelly-ST-20240802-06
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The 3 Inch Class 150 LB Y strainer is manufactured in accordance with the ASME B16.34 standard. Constructed from ASTM A352 LCB, this Y-type strainer features a bolted cover and a 100-micron filter screen for efficient filtration. Its connection type is raised face (RF), ensuring a secure and reliable fit in various applications.

Request a quote

Quick Detail

Type:	Y Strainer
Pressure:	Class 150 LB
Size:	3 Inch
Connection:	RF
Body Material:	ASTM A352 LCB, Carbon Steel
Design Norm:	ASME B16.34
Face to Face Dimension:	ASME B16.10
Flange Dimension:	ASME B16.5
Test & Inspection Code:	API 598
Temperature:	-46°C to 345°C
Applicable Medium:	Water, Oil and Gas

Detail Information

On this page

ASTM A352 LCB Y Type Strainer, ASME B16.34, 3 Inch/DN80, Class 150 LB, Carbon Steel.

Features

1. The Y-Type Strainer efficiently filters out particles and debris from fluids, ensuring that only clean fluid reaches downstream equipment like pumps and valves.

2. The Y-Type Strainer's design allows for quick and easy access to the strainer element, making maintenance tasks like cleaning and replacement straightforward and time-efficient.
