ASME B16.34 Floating Ball Valve, ASTM A182 F316, 1500 LB, 1IN

Name: ASME B16.34 Floating Ball Valve, ASTM A182 F316, 1500 LB, 1IN
SKU: Kelly-BV-20240921-03
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The 1-inch Class 1500 LB floating ball valve is crafted in accordance with ASME B16.34 standards, ensuring top-notch performance and safety. The valve body is constructed from ASTM A182 F316 material, providing excellent corrosion resistance and durability. Designed with a 3-piece structure and a floating ball configuration, this valve features a full bore for maximum flow capacity. It incorporates anti-fire, anti-static, and anti-flying valve stem designs for enhanced safety. The valve is connected using NPT and operates with a lever mechanism, making it user-friendly and efficient for various applications.

Request a quote

Quick Detail

Type	Floating Ball Valve
Size	1 Inch
Pressure	CL 1500 LB, PN250
Connection	NPT
Operation	Lever
Body Material	ASTM A182 F316
Design Norm	ASME B16.34
End to End Dimension	Manufacturer's Standard
Screwed End	ASME B1.20.1
Fire Safe Test	API 607
Test & Inspection Code	API 598
Temperature	-46°C to 290°C
Applicable Medium	Water, Oil and Gas

Detail Information

On this page

Features

1. Minimal fluid resistance promotes efficient flow within the system.

2. Floating ball valves feature a straightforward design with few moving parts, ensuring easy maintenance and a long service life.
