Tri-axle Dropside Trailer, 40ft, GVWR 48 Ton, Payload 40 Ton
Key Specifications / Features
Justsun New Tri-axle Dropside Trailer, Drop Side Trailer for Sale. Our 40ft Tri-axle Payload 40 Ton Dropside Trailer with GVWR 48 Ton, Tare Weight 8000 kg (8 Ton) Is Designed for Your Individual Requirements. With Added Strength, Flatbed 3-axle Dropside Trailer with Superior Quality Can Endure Constant Opening & Closing Action.
Request a quote
Detail Information
Product: Dropside Trailer.
Gross Weight: 48 Ton (Approx. 105,821 lbs).
Payload: 40 Ton (800,00 lbs).
Axle: 3 Axles.
SPECIFICATION
Gross Weight: 48 Ton (Approx. 105,821 lbs).
Payload: 40 Ton (800,00 lbs).
Axle: 3 Axles.
SPECIFICATION
| 40FT Side Wall Semi Trailers | ||
| Feature | Carry 1X20 FT, 1X40 FT, or 2X20 FT container; Carry Bulk cargo |
|
| Dimension(L*W*H) | 12600*2500*2300mm | |
| The Height of Wall | 800mm | |
| Mainframe | Heavy duty and extra durability design, made of high tensible low carbon alloy steel Q345B and I beam welded by automotive arc-submerge process | |
| Model | JS9402TJZW | JS9400TJZW |
| Axles | 3 | 2 |
| Payload(kgs) | 50000 | 40000 |
| Curb weight(kgs) | 8200 | 7300 |
| Kingpin | The world-famous JOST brand bolt-in/welded type 3.5”/2” | |
| Landing gear | JOST brand two-speed manual operation 19” | |
| Tire size | 11.00R20, 11R22.5, 12R22.5, 315/80R22.5 and 385/65R22.5 | |
| Rim size | 8.25*22.5, 9.00*22.5 and 11.75*22.5 | |
| Axle | Original BPW-12T/FUWA-13T | |
| Suspension | Germany type with 12pcs of leafs spring/Fuwa brand with 8pcs of leafs spring/Airbag suspension | |
| Brake system | Dual line with WABCO brand Re-6 emergency relay valve, MBA brand T30/30 air chamber and 46L air tank | |
| Electric system | One unit of 24V 7-pin ISO standard socket; with brake light, turn light, reverse light, side light, fog light and reflector; one set of 6-pin standard cable | |
| Container locks | 12(for 1x20GP, 2X20GP and 1X40HQ) | |
| Painting | S.A.2.5 standard sandblasting, two coats of anti-corrosion prime and one coat of finish painting | |
| Accessory | One tool box and one set of standard tool | |
| We can manufacture the trailers according to customers’ designs and requirements. | ||
