24kW Diesel Generator Set, Deutz D226B-3D, Trailer Mounted

Name: 24kW Diesel Generator Set, Deutz D226B-3D, Trailer Mounted
SKU: CGS-20250312-TMGS-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

The Soundproof Diesel Generator Set from a reputable manufacturer features a trailer-mounted design for easy mobility and convenience. It is powered by the reliable Deutz D226B-3D engine and equipped with the Stamford PI142F alternator. This generator set offers a rated power of 24kW (30kVA), operating at 50 Hz with a current output of 39A. Notably, it boasts an impressive fuel efficiency of 0.07 liters per hour, making it an efficient and portable solution for various power needs.

Request a quote

Detail Information

Product Name: Trailer Mounted Diesel Generator Set, Mobile Generator Set
Fuel: Diesel
Engine: Deutz D226B-3D
Alternator: Stamford PI142F
Prime Power: 24kW, 30kVA
Standby Power: 26kW, 33kVA
Power Factor: 0.8
Frequency: 50 Hz
Output Voltage: 400/230 V
Rated Current: 39A
Oil Consumption: 0.07 L/H
Dimension (Soundproof): 2300 * 900 * 1250 mm
Weight (Soundproof): 1090 kg

Engine Specifications

Engine Brand	Deutz
Engine Model	D226B-3D
Number of Cylinders	3 Cylinder in-line
Bore	105 mm
Stroke	120 mm
Displacement	3.12 L
Cooling Fan Air Flow	155 m³/min
Compress Air Flow	2.83 m³/min
Exhaust Gas Flow	6 m³/min
Exhaust Gas Temperature	470 °C
Lubrication Oil Capacity	7.75 L
Cooling Water Capacity	17 L
Starting Voltage	24 V
Engine Max. Output Power	33kW

Alternator Specifications

Brand	Stamford
Model	PI142F
Rated Output	32kVA
Frequency	50 Hz
Altitude	≤1000 m
Insulation	Class H
Protection Grade	IP23
Alternator Options	Leroy Somer, Marathon, Mecc Alte, Chinese brand Brushless

Control Panel Specifications

Controller Brand	Deepsea
Controller Model	DSE7320
Functions	Automatic genset start/stop
	Automatic battery charger
	Emergency stop
	AMF (Automatic Mains Fault)
	Remote control
	Micro-processor based design
	LED alarm indication and sound alarm
Display Features	Generator voltage (Uab, Ubc, Uca)
	Generator current (Ua, Ub, Uc)
	Generator temperature (°C/°F)
	Generator frequency (Hz)
	Generator power (kW, kVA, kWh, kVAr, kVArh, kVAh)
	Generator start count (Max 999999)
	Generator pressure (kPa/Psi/Bar)
	Charging voltage (V)
	Battery voltage (V DC)

Protection and Alarms

Protection	Alarm Features
Over/Under Speed Alarm and Shutdown	High Engine Temperature Alarm and Shutdown
Start/Stop Failure Alarm	Over Load Alarm and Shutdown
Over Current Alarm and Shutdown	Low and High Battery Voltage Alarm
Under/Over Generator Voltage Alarm	Loss of Speed Signal Alarm and Shutdown
Low Oil Pressure Alarm and Shutdown	Charge Fail Alarm
