Timer Controlled Electric Motorized Ball Valve, DN20, 150 LB
Key Specifications / Features
Detail Information
Product Name: Timer Controlled Electric Motorized Ball Control Valve
Size Range: 1/2 Inch - 1 Inch, DN15-DN25
Pressure Rating: PN10, Class 150 LB
Body Material: Brass, SS 304, SS 316(optional)
Valve Ball: PVC, UPVC, Brass, Stainless Steel(Optional)
Sealing Material: SEPDM
Actuator Material: Engineering Plastics
Keeping Valve Open Time: 0H:0M: OS-99H:59M:59S
Temperature Of Media: 2°C to 9°C
Ambient Temperature: -15°C to 50°C
End Connection: BSP Thread
Medium: Water, Air
Leakage: Zero leakage, Return difference: ±2.5%
Send your message to this supplier
FAQs
Generally speaking, production will start after receiving the advance payment and confirming the drawings. The exact delivery time depends on your order and quantity.
For OEM orders, the lead time will be around 50-70 days after receiving deposit.
For commodity valves in stock, such as GGC (Gate, Globe, Check) low-pressure carbon steel valves (WCB valves below Class 300 up to 24”), we maintain a large inventory and can deliver them promptly upon request.
For newly manufactured valves, the standard lead time is typically 8 to 12 weeks. For expedited orders, special designs, or large quantities, please contact us directly to confirm the lead time.
