Multi-Turn Electric Globe Control Valve, Cast Iron, DN150, PN20

Name: Multi-Turn Electric Globe Control Valve, Cast Iron, DN150, PN20
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Introducing the Electric Globe Control Valve Factory, offering Two-Way functionality in sturdy Cast Iron construction. Equipped with a reliable Multi-Turn Actuator, these valves ensure precise flow regulation in pipelines ranging from 2 to 16 inches (DN50-DN400) with PN16, PN20, or PN25 pressure ratings. Unlike ball valves, these globe valves feature a movable plug or disc element and a stationary ring seat within a spherical body. With Flanged Ends Type PN16, the bonnet securely contains fluids, gases, or slurries, providing leakproof closure. Ideal for diverse applications, these two-port valves offer robust performance and reliable control for fluid management needs.

Request a quote

Detail Information

SPECIFICATIONS
Product Name: Electric Globe Control Valve
Size Range: 2 Inch - 16 Inch, DN50-DN400
Class Rating: PN16, PN20, PN25
Key Features: Two Way, Two Port, Cast Iron, Multi-Turn
Materials: Cast Iron, Stainless Steel
Sealing Material: PTFE
End Connection: Flanged
Medium: Control of Water, Air, Gas, Oil, Liquid, Steam
Optional Accessories: Torque Protectors, Dehumidify Heater, Stainless Steel Coupling & Yoke
Applications: Food & Beverage, Water & Wastewater, Ultra Pure Water, Desalination, Chemical, Textile, Pharmaceutical, Pulp & Paper, Mining, Boiler and Power Industries
Power Supply:
Conventional: single-phase 220v, three-phase 380v
Special: three-phase 400v, 415v, 660v(50Hz, 60Hz)
Working Environment:
Ambient temperature: -20°C to + 60°C (special temperature environment can be customized)
Relative humidity: 95% (at 25°C)
Protection level: Outdoor type and explosion-proof type are IP55 (IP65, IP67, IP68 can be provided for special order)
