Y Pattern Globe Valve, A105N, 2500 LB, 1/2 IN, API 602

Name: Y Pattern Globe Valve, A105N, 2500 LB, 1/2 IN, API 602
SKU: 1852050
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

We proudly export high-quality ASME B16.34 Y Pattern Globe Valves from China, designed to meet top industry standards, including API 602 and ASTM A105N. This robust valve, with a 1/2 inch size and rated for Class 2500 LB pressure, is engineered for superior performance in high-pressure environments. Featuring a Y pattern design, the valve ensures efficient flow control and reduced pressure drop. It is equipped with a pressure seal bonnet, enhancing its sealing capabilities and reliability. The valve also includes an Outside Screw and Yoke (OS&Y) mechanism for precise operation and is designed with Butt Weld ends for secure and durable connections. Ideal for critical applications requiring high pressure and precise fluid regulation, our Y Pattern Globe Valve combines durability, efficiency, and advanced engineering to meet demanding industrial needs.

Request a quote

Detail Information

ASME B16.34 Y Globe Valve, 1/2 Inch, 2500 LB, Pressure Seal Bonnet, A105N Body, for Power Plant.

Valve Description:

1852050 Globe Valve
Design Standard: ASME B16.34, API 602
Structure: Bolted Bonnet, Pressure Seal Bonnet, Welded Bonnet, Bonnetless
Nominal Size: 1/2 Inch
Nominal Class: 2500 LB
Bore Type: Reduced
Body Material: ASTM A105N, ASTM A182 F11, ASTM A182 F22, ASTM A182 F316, ASTM A182 F91
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
Operation: Handwheel
Applications: Oil and Gas Industry, Power Generation, Chemical Processing, Water Treatment Plants.
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316
Face to Face: MFG'S
Test and Inspection: API 598
Bonnet Types: Y Globe Valves can feature various bonnet designs, such as bolted or welded, depending on the application and pressure requirements.

Key Features:

1. Rising Stem with Handwheel for Accurate Control
2. Options for Swivel, Plug, or Needle Disc
3. Backseat for Additional Leak Prevention
4. Live Load Packing for Effective Sealing
5. Y-Pattern Design for Optimal Flow Control
6. Outside Screw & Yoke (OS&Y) for Enhanced Reliability
7. Compact and Durable Construction for High-Temperature and High-Pressure Applications

Product Line
Body Material:	Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter:	1/2 Inch - 2 Inch (DN15-DN50)
Pressure Range:	Class 800 LB - 4500 LB
Working Temperature:	-29°C - +525°C
Operation:	Manual or Actuated
End Connection:	BW/SW/NPT

Send your message to this supplier

Name *

Company

Email *

Phone

Message *

FAQs

What is OS&Y?

OS&Y stands for Outside Screw and Yoke. This design places the threaded stem outside the valve body, with the yoke supporting the stem. It allows users to visually verify whether the valve is open or closed by observing the stem’s position.

OS&Y gate valves are commonly used in fire protection systems, including sprinklers, hydrants, and standpipes, due to their reliability and clear open/close indication.

Что такое OS&Y?

"Outside Screw and Yoke" (наружный винт и вилочный рычаг) — это конструкция клапана, при которой резьбовой шток (винт) находится снаружи корпуса клапана, а вилочный рычаг (йок) удерживает шток на месте. В отличие от других типов затворных клапанов, положение клапана OS&Y (открыт или закрыт) можно визуально определить по положению штока.

Затворные клапаны OS&Y широко используются в системах пожаротушения, системах гидрантов и стояковых системах. Их способность чётко показывать, открыт клапан или закрыт, делает их важными для безопасности и соблюдения нормативных требований.
