API 6A Compact Ball Valve, F60/F65, 1-13/16 Inch, 2000 PSI

Name: API 6A Compact Ball Valve, F60/F65, 1-13/16 Inch, 2000 PSI
SKU: BV-181105001
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a leading compact ball valve manufacturer in China, we specialize in high-performance valves designed to meet API 6A standards. Our valves feature ASTM A694 F60/F65 bodies and 17-4PH stainless steel trims, ensuring durability and reliable operation under demanding conditions. Available in 1-13/16 inch sizes with a 2000 PSI rating, these valves can be configured with RTJ or butt-weld (BW) ends and operated via lever, gear, or actuator mechanisms. Ideal for critical oil and gas applications, our compact ball valves combine precision engineering, robust materials, and versatile operation for superior performance.

Request a quote

Detail Information

Valve Description:
181105001 API 6A Compact Ball Valve
Design Standard: API 6A/API 6D
Structure: 1pc body
Nominal Size: 1-13/16 Inch to 11 Inch
Nominal Class: 2000-15000 PSI
Bore Type: Full Bore or Reduced Bore
End Connection: RTJ, BW, and Hub
Operation: Lever/Gear/Bare Shaft
Body Material: AISI 4130/ASTM A694 F60/ASTM A694 F65
Trim Material: 4140/F51/17-4PH/Inconel Trim
Seat Insert: POM/PEEK or hard faced
Face to Face: ASME B16.10/MFG'S
Test and Inspection: API 6A/ API 6D

Key Features:
Compact design with short face to face and low weight
Low torque
Easy for maintenance
Removable seat retainer to reduce torque and easy for repair

• Material Class: AA, BB, CC, DD, EE, FF, HH
• Temperature Class: L, N, P, S, T, U, V, X, Y
• Specification: PSL1 - PSL3G
• Performance: PR1, PR2

Product Range:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1-13/16 - 11 Inch
Pressure Range: 2000PSI - 15000PSI
End Connection: RF, RTJ, BW, HUB
Working Temperature: -26°C - +150°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
