2 Inch Gate Valves, API 602, Stainless Steel F316L, 300 LB

Name: 2 Inch Gate Valves, API 602, Stainless Steel F316L, 300 LB
SKU: BV-GTV-20250312-07
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a leading API 602 gate valve factory, we manufacture high-quality stainless steel gate valves designed for durability and precision. This model features an ASTM A182 F316L stainless steel body, providing excellent corrosion resistance for demanding applications. With a 2-inch (DN50) size, Class 300 LB (PN50) pressure rating, and integral flanged ends, it ensures secure and efficient flow control. Built to ASME B16.10 face-to-face dimensions, this valve meets industry standards for reliable performance in oil and gas, chemical, and marine industries.

Request a quote

Detail Information

Integral Flange Gate Valves, API 602, F316L.

Valve Description:
Product Name: Small Size Gate Valve, Integral Flange.
Design Standard: API 602
Body Material: ASTM A182 F316L
Nominal Size: 2 Inch, DN50
Nominal Class: Class 300 LB, PN50
End Connection: Flange Ends
Face to Face: ASME B16.10
Test and Inspection: API 598

Technical Parameters And Characteristics

Product Item	Small Size Gate Valve
Nominal Diameter	1/4 Inch - 4 Inch
Design Temp.	-196°C - 573°C
Design Pressure	Class 150 LB - Class 4500 LB
Material	Carbon Steel, Stainless Steel, Alloy Steel, Bronze
Design Standard	API 602, BS 5352
Face to Face	Manufacturer Standard, ASME B16.10
Connection End	NPT, SW, BW, Flange
Test standard	API 598, ISO 5208
Operation	Hand Wheel, Electric
Application	Power Station, Petroleum, Chemical Engineering
Function 1	Bolted Bonnet, Welded Bonnet, Pressure Seal Bonnet
Function 2	Solid Wedge
Function 3	Full Bore, Reduce Bore
Function 4	Integral Flanged Ends, Welded on Flanged Ends
