Smart Home IOT Safety Testing Carbon Dioxide Detector

Aug 09, 2022

Air Quality Sensor Smart Home IOT Safety Testing Detector Carbon Dioxide Gas Sensor Module

Model Number: CS200
Type: CO2 sensor, Gas Sensor
Place of Origin: Sichuan, China
Brand Name: Pulse sensor
Usage: indoor CO2 concentration detection
Theory: NDIR
Output: UART TTL
Description: Carbon Dioxide Gas Sensor
Measuring range: 400-5000ppm
Power supply: DC (5.0±0.1)V
Temperature range: -30°C - 70°C
Size: 33*21*17.2 mm
Features: High Precision
Certificate: ROHS, REACH, ISO 9001
Power-on time: 30s
Accuracy: ± (50ppm+5% reading)
Supply Ability: 5000 Piece/Pieces per Day

Parameter	Index
Measuring principle	NDIR: Non‐dispersive Infrared
Measuring range	400-5000ppm
Measuring precision	±（50ppm+5% reading）
Power-on stability time	30s
Data refresh frequency	2s
Zero cycle	Automatically calibrated once for 15 consecutive power-on days (optional) (automatic calibration is not enabled by default for 1-15 days)
Working condition	-10-50°C；0-95%RH（non-condensing）
Storage condition	-30-70°C；0-95%RH（non-condensing）
Working voltage	DC (5.0±0.1)V，Ripple <50mV
Average working current	＜40mA
Communication Interface	UART_TTL(3.3V)
SIZE	332117.2 mm
Lifetime	≥10 years
