Indoor And Outdoor Carbon Dioxide Sensor
Long Service Life Indoor And Outdoor Concentration Detection Carbon Dioxide Sensor
Model Number: CS200
Brand Name: PULSE
Type: CO2 sensor
Weight: 15g
Output: UART TTL
Range: 400-5000ppm
Measuring type: CO2
Working current: <40mA
Description: Carbon dioxide sensor
Working condition: -10°C - 50°C; 0 - 95%RH (non-condensing)
Storage condition: -30°C - 70°C; 0 - 95%RH (non-condensing)
Data interface: UART_TTL (3.3V)
Working voltage: DC (5.0±0.1)V, Ripple <50mV
| Product Model | CS200 |
| Brand | PULSE |
| Origin | Chengdu, China |
| Size（mm) | 33*21*17.2 mm |
| Measuring type | CO2 |
| Range | 400-5000ppm |
| Weight | 15g |
| Working current | ＜40mA |
| Working voltage | DC (5.0±0.1)V，Ripple <50mV |
| Working condition | -10-50°C；0-95%RH（non-condensing） |
| Storage condition | -30-70°C；0-95%RH（non-condensing） |
| Data interface | UART_TTL(3.3V) |
