Air Quality Detection Sensor, PM2.5, CO2, TVOC, UART TTL

Sep 27, 2022

Direct Wholesale Air Quality Detection Module Temperature Sensor

Weight: 45g
Model Number: MM201A
Measuring type: PM2.5, CO2, VOC, etc
Working current: 200mA

Range:
PM2.5: 0-600ug/m3, CO2: 400-5000ppm, TVOC: 0-9.999mg/m3
Working voltage: DC 5±0.5V, Ripple <100mV

Working condition:
Temperature: 0-50°C; humidity: 15-90% RH.

Storage condition:
Temperature: -20°C-60°C; humidity: 15-90% RH.
Data interface: UART TTL, 9600 bps

Packaging & delivery
Selling Units: Single item
Single package size: 6.9 X 5.15 X 1.8 cm
Single gross weight: 0.045 kg

Product Model	MM201A
Brand	PULSE
Origin	Chengdu, China
Size（mm)	6951.518
Range	PM2.5: 0-600ug/m³ CO2: 400-5000ppm TVOC: 0-9.999mg/m³
Weight	45g
Working current	200mA
Working voltage	DC 5±0.5V，Ripple <100mV
Working condition	Temperature: 0°C - 50°C; humidity: 15-90% RH.
Storage condition	Temperature: -20°C - 60°C; humidity: 15-90%RH.
Data interface	UART TTL, 9600 bps
