Flanged Knife Gate Valve, DN80–DN1500, DI, CS, Rubber Sleeve

Product Name: Flanged Knife Gate Valve
Size Range: DN80–DN1500, 3-60 Inch
Pressure Rating:
DN80–DN600: 6 bar, PN6
DN650–DN1050: 5 bar, PN5
DN1200–DN1350: 3 bar, PN3
DN1500: 2 bar, PN2
Operating Temperature: Standard sleeve up to 75°C, maximum 180°C
Sleeve Material: Pure Rubber Compound
The flanged knife gate valve is equipped with heavy-duty, full-port elastomer sleeve, providing ultimate shutoff for heavy slurry applications.

Standard Configuration

Ductile iron or carbon steel body
SS 316L stainless steel gate plate
Carbon steel actuator mounting bracket
Flat body flanges compatible with international flange dimensions
Natural rubber sleeves and sealing gaskets for standard temperature
DN250–DN1500 with carbon steel retainer flanges and natural rubber seals

Lining Configuration

Internal reinforcement ring
Maintains roundness
Resists shear forces during operation
Protects internal sealing surfaces

Product Features

Designed to meet various requirements for abrasion, corrosion, temperature, and pressure;
Functions both as a pump body and for slurry handling, performing effectively even with ungranulated and high-density materials;
Provides 100% isolation with bubble-tight sealing for absolute zero leakage;
Heavy-duty, field-replaceable elastomer sleeves with internal reinforcement rings;
Double-gate design enables bi-directional flow sealing;
Unobstructed or dynamically stabilized airflow minimizes valve pressure drop;
Prevents any solid particle accumulation on the gate that could hinder valve closure;
No metal parts are exposed to slurry contact;
No need to adjust or lubricate packing, eliminating leakage and maintenance issues;
Flexible frame (bracket) design allows for installation onto existing gate stem nuts.
Applications: Mining, Mineral Processing, Power Generation, Chemical Industry, Pulp and Paper Industry, Cement Industry
