Electric Actuated Butterfly Valve, CS, SS, 1-24 Inch, CL150

Product Name: Electric Soft Seal Butterfly Valve
Body Material: Cast Iron, Carbon Steel, Stainless Steel, etc
Nominal Diameter: DN25-DN600, 1-24 Inches
Rated Pressure: 1.0MPA 1.6MPA, PN10, PN16, Class 150 LB
Connection Method: Clamped, Flanged
Ambient Temperature: -10°C to 60°C
Medium Temperature: PTFE -10°C to 100°C, POB -20°C to 250°C

Electric Actuator Parameters

Available Voltage: AC220V, AC380V, AC110V, AC24V, DC24V, DC48V, DC220V
Protection Level: IP65, IP66, IP67, IP68
Explosion-proof Grade: Ex dII BT4, Ex dII CT4
Control Method: Sourceless Switch Type, Modulating Type, Intelligent Type
Stroke Range: 0-90°, 0-180°
