Carbon Steel Gate Valve, WCB, DN15-DN100, Hard Seal, Threaded
Product Name: Carbon Steel Gate Valve, Hard Seal
Design Standard: ASME B16.34
Materials: Carbon Steel, Cast Steel (ASTM A216 WCB)
Size: DN15-DN100, 1/2-4 Inch
Working Pressure: PN16-PN100, Class 150-600 LB
End Connection: Internal Threaded
Operation: Handwheel
Face to Face Standard: ASME B16.10
Testing Standard: API 598
Medium: Water, Oil, Gas, etc.
Carbon Steel Gate Valve Dimension Table
|
Nominal Diameter |
Weight (kg) |
Length (mm) |
|
DN15 |
0.73 |
61.5 |
|
DN20 |
0.9 |
66 |
|
DN25 |
1.09 |
70 |
|
DN32 |
1.68 |
83 |
|
DN40 |
2.39 |
95 |
|
DN50 |
3.29 |
107 |
|
DN65 |
5.1 |
123 |
|
DN80 |
9.75 |
138 |
|
DN100 |
11.9 |
148 |
