Air-Operated Diaphragm Pump, PP, PVDF, 2 Inch, 0-548 L/min

Product Name: Air-Operated Diaphragm Pump
Type: Pneumatic Diaphragm Pump
Body Material: PP, PVDF
Maximum Flow Rate (flooded inlet): 0-548 L/min (liters per minute)
Suction Lift: Dry suction 2 meters, Wet suction 5 meters
Maximum Lift: 0-65 Meters
Outlet pressure: 0.15-0.7 MPa
Maximum Particle Size: 6.5 mm
Inlet threads type: ANSI Flange PN20
Inlet threads size: 2 Inch ANSI Flange
Air inlet pipe size: 12 mm
Air inlet pressure range: 0.15-0.7 MPa
Net Weight: 28 KG (PP), 40 KG (PVDF)
