Three Pieces Floating Ball Valve, 1 Inch, 800 LB, FNPT

Explore premium quality Three-Piece Body Ball Valves at our factory, available in 1 Inch size with 800 LB (pound) and PN130 pressure ratings. Designed in a Floating-type configuration, our valves are constructed with ASTM A350 LF2 material, conforming to API 6D, API 608, and ISO 17292 standards. Featuring a resilient RPTFE seat and FNPT threaded end, these valves guarantee reliable performance and durability for various industrial applications.

1 inch, 800 LB, Floating Ball Valve, FNPT Threaded End, ISO 17292, LF2 body with 316 Trim, RPTFE seat and lever operation

Valve Description:
1812034 Floating Ball Valve 1BB8NLF2
Design Standard: API 608, ISO 17292, API 6D
Structure: Three pieces body, Side Entry, Bolted Bonnet, Soft Seat
Nominal size: 1 Inch, DN25
Nominal class: 800 LB
Bore Type: Full Bore
End Connection: FNPT
Operation: Lever Lockable
Body Material: ASTM A350 LF2
Trim Material: ASTM A182 F316, RPTFE
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Anti-static Device, Fire Safe, Anti-Blowout Stem, Locking Device

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 2 Inch (DN15 - DN50)
Pressure range: Class 150 - 2500 LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +150℃
Operation: Lever, Spring Return Lever, Pneumatic Actuator
